Blackmagic CINSTUDMFT/G26PDK Studio Camera 6K Pro

SKU: CINSTUDMFTG26PDK
$3,699.00 $4,099.00
Out of Stock, contact for ETA
NOTIFY ME WHEN BACK IN STOCK
This product is unavailable
Description

Designed as the ultimate studio camera, Blackmagic Studio Camera 6K Pro adds a larger 6K Super 35 sensor and EF lens mount for true cinematic images in live production. There are built in ND filters that let you reduce the amount of light entering the camera, allowing you to work in a wider range of situations, including in bright sunlight. Plus stream direct to the internet with built in streaming! You also get 12G‑SDI, HDMI and 10G Ethernet which allows all connections on a single cable for a SMPTE style workflow that's much lower cost.

A full range of accessories and specifications are available on the Blackmagic Design product page, please contact our expert sales team for a custom quote!

Camera Features

Effective Sensor Size - 23.10mm x 12.99mm (Super 35)
Lens Mount - Active EF mount.
Lens Control - Iris, focus, zoom on supported lenses.
Dynamic Range - 13 Stops.
Dual Native ISO - 0dB and 18dB gain.
Sensitivity at 0dB Gain - f11 with 2160p59.94; f12 with 2160p50; at 2,000 lux with 89.9% reflectance.
Signal to Noise Ratio - 64.62dB for 2160p; Ultra HD scaled from 5.3K
Recording Resolutions
6144 x 3456 (6K) up to 50 fps
6144 x 2560 (6K 2.4:1) up to 60 fps
5376 x 3024 (5.3K 16:9) up to 60 fps
3840 x 2160 (Ultra HD) up to 60 fps
Video Output Standards
2160p, 1080p, 1080i
Frame Rates
Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps supported.
Off-speed frame rates 5 ‑ 50 fps in 6K, and 5 ‑ 60 fps for all other recording resolutions.
Built in ND Filters - Four position ND filter with clear, 2‑stop, 4‑stop and 6‑stop IR ND filters.
Focus - Auto focus available using compatible lenses.
Screen Dimensions - 7 inch 1920 x 1200
Screen Type - LCD capacitive touchscreen.
Screen Brightness - 2000 nits
Controls - Touchscreen camera settings and menus with rotary settings dial, program button, F1, F2 and F3 assignable function buttons, brightness contrast and peaking dials.
Mounting Options - 2 x 1/4 inch tripod mount.; 1 x 3/8 inch tripod mount.

Connections

SDI Video Inputs - 1
SDI Video Outputs - 1
SDI Rates - 1.5G, 3G, 6G, 12G.
HDMI 2.0 Video Outputs - 1
Analog Audio Input - 2 x XLR analog switchable between mic and line levels. Phantom power support; 1 x 3.5mm Stereo Input. Can also be used for Timecode input.
Analog Audio Output - 1 x 5-pin XLR for talkback headset; 1 x 3.5mm TRRS mini jack for headphones with mic.
SDI Audio Output - 2 channels of program audio embedded in 1.5G/3G/6G/12G-SDI; 2 talkback channels on 15 and 16.
Reference Inputs - Tri-Sync or Black Burst when used with optional Blackmagic Studio Converter.
Remote Control - Remote camera control over SDI, HDMI or Ethernet.
Ethernet - 10Gb/s
Computer Interface - 2 x USB Type‑C 3.1 Gen 1 (up to 5Gb/s) expansion ports for external recording and focus / zoom demand connection. Software updates using USB‑C Port A.
