Blackmagic CINSTUDMFTUHDMRG2 Micro Studio Camera 4K G2
Description
Blackmagic Micro Studio Camera 4K G2 is an amazing, broadcast quality live production camera in a tiny body. The Four Thirds sensor has 13 stops of dynamic range, incredible low light performance and produces stunning Ultra HD images in all lighting conditions. 12G-SDI Micro BNC connectors support 10-bit uncompressed video up to 2160p60 and 2 channel audio on the output. The input supports tally, camera control, control of the built-in color corrector plus lens control, from an ATEM switcher. Or when using an ATEM Mini switcher, the HDMI connector will output 1080 and support all control features. Plus it's even a Hollywood quality cinema camera because it can record Blackmagic RAW to external USB-C drives. With multiple mounting points, place Blackmagic Micro Studio Camera 4K G2 where no other camera will go!
A full range of accessories and specifications are available on the Blackmagic Design product page, please contact our expert sales team for a custom quote!
Camera Features
Effective Sensor Size - 17.78mm x 10mm (Four Thirds)
Lens Mount - Active MFT Mount.
Lens Control - Iris, focus, zoom on supported lenses.
Dynamic Range - 13 Stops.
Dual Native ISO - 0dB and 18dB gain.
Sensitivity at 0dB Gain - f11 with 2160p59.94; f12 with 2160p50;at 2,000 lux with 89.9% reflectance.
Signal to Noise Ratio - 63dB for 2160p.
Shooting Resolutions - 3840 x 2160 (Ultra HD) up to 60 fps.
Frame Rates - 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 frames per second. Off-speed frame rates up to 60 fps in Ultra HD.
Focus - Auto focus available using compatible lenses.
Metadata Support - Automatically populated lens data from electronic Micro Four Thirds lenses. Automatic recording of camera settings, motion sensor data plus slate data such as project, scene number, take and special notes. A 3D LUT can also be embedded in metadata of Blackmagic RAW files.
Mounting Options - 1 x 1/4 inch (top), 3 x 1/4 inch (bottom).
Connections
SDI Video Inputs - 1 x 12G‑SDI Micro BNC
SDI Video Outputs - 1 x 12G‑SDI Micro BNC
SDI Rates - 3G, 6G, 12G.
HDMI 2.0 Video Outputs - 1
HDMI Video Outputs - 1 x HDMI Type A output. HDMI output is always HD, up to 1080p60.
Analog Audio Input - 1 x 3.5mm Stereo Input. Can also be used for Timecode input.
Reference Inputs - Program SDI Input on camera.
SDI Audio Output - 2 channels of program audio embedded in 3G/6G/12G-SDI.
HDMI Audio Outputs - 2 channels 48 kHz and 24‑bit.
Remote Control - Remote camera control over SDI, HDMI or USB Ethernet with suitable adapter.
Computer Interface - 1 x USB Type‑C 3.1 Gen 1 (up to 5Gb/s) expansion ports for external recording and focus / zoom demand connection. Software updates using USB‑C Port.
