Chamsys QuickQ Rack+ 6-Universe 19" Rack Mountable Lighting Console

SKU: CS100703
$6,299.00
Out of Stock, contact for ETA
By Chamsys
NOTIFY ME WHEN BACK IN STOCK
Description

Chamsys QuickQ Rack+ is a small rack-mountable lighting controller designed for installations and remote system operation. It outputs six universes of control via direct DMX or Art-Net/sACN and includes two RDM-enabled DMX outputs for automatic detection and patching of RDM compliant fixtures. The unit has 10 playback/execute buttons, four 10Scene ports, in-built Wi-Fi, and two network ports for separating lighting and control data. It can be used as a desktop box or rack mounted with the supplied rack ears.

  • 6 Universe output via Art-Net/sACN
  • 2 RDM-Enabled DMX Outputs
  • In-Built Wi-Fi for easy connection to the remote app on iOS & Android devices
  • Dual Network ports allowing separation of Lighting and Control Data
  • User Interface Modelled on smartphone icon interfaces for ease of use
  • Intuitive interface allowing simple control of all fixture attributes
Universes supported 6
Direct DMX Outputs 5-Pin XLR 2
10Scene Buttons 10
10Scene Ports 4
External Monitor 1920 x 1080 HDMI
Inbuilt Wi-Fi Yes
Network Port 2
USB Ports 2
Audio Input 1
Audio Output 1
MIDI Ports in/out Yes
Power Input TrueCon Power Input: 90-250v AC
Max Power Consumption (mains) 60w
Max Number of DMX Channels 3072
Max Number of Fixtures Supported 3072
Max Number of Cue Stacks 2000
Max Number of Chases 2000
Max Number of 10Scene Zones 10
Midi & Midi Timecode Supported Yes
OSC Supported Yes
RDM Autopatch for fast show patching Yes
Fixture library of over 60,000 fixture files Yes
Built in FX generator Yes
Colour picker and Gel inbuilt Gel library Yes
Offline designer software available for Windows and Mac Yes
Simple Hot-Takeover mode allowing an external console to take control Yes
Width (without ears) 403mm
Depth 195mm
Height 45mm
Weight 3.1kg
